What does S355J0WP means ?

S355J0WP is a weathering steels grade that is under the European standard EN 10025-5. The S in the S355J0WP coil indicates structural steel, while 355 is the minimum yield strength in MPa. The J0 designation in S355J0WP strips indicates that the steel has undergone impact testing at 0 degrees C. The W denotes its weathering properties. S355j0wp corten is primarily used for outdoor structural applications for its weathering resistance and structural strength. The Weathering steel S355J0WP plate is ideal for various other outdoor applications.

Table of content

We are a leading supplier of BS EN10025 s355j0wp sheets in India.

S355J0WP steel plate

What is the difference between JR and J0 steels?

S355J0WP structural steel plate undergoes impact testing at a lower temperature. This is important in applications where low temperature conditions are a factor. J0 steels can offer superior impact resistance at colder temperatures than JR steels. Thus, the Corten steel S355J0WP plate is suitable for structures in sub-zero environments or where a higher level of toughness is required.

As a stockist we focus on the supply and prompt delivery of cut-to-size Jindal and Uttam make corten steel s355j0wp plate in Mumbai.

EN10025 S355J0WP plate

EN10025 S355J0WP plate

S355J0WP steel sheet

S355J0WP steel sheet

S355J0WP structural steel plate

S355J0WP structural steel plate

What is S355J0WP equivalent to?

S355J0WP sheet material is a weathering steels grade equivalent to ASTM A242 and COR-TEN A. ASTM A242 is a specification for high strength structural steels with atmospheric corrosion resistance. COR-TEN A is a brand name for weathering steels. S355J0WP shares similar properties like enhanced resistance to atmospheric corrosion, good weldability and high strength with these.

Fully authorised stockholder of s355j0wp structural steel plate up to 2 to 460 mm thickness and 3200mm width, know complete specification

S355J0WP steel plate specification

S355J0WP steel plate specification



Thickness Width Length
2 to 460mm 1500 to 3200 mm 6000 to 12000 mm
Standard Application Delivery State
EN 10025 architecture, pylons, freight wagons hot/cold rolled
normalized, quneched
Only here will you have the opportunity to acquire weathering steel s355j0wp coil and strip at a low cost; shop for many types online to save money.
Types of s355j0wp plate

Corten steel S355J0WP coil

Corten steel S355J0WP coil

  • air preheater
  • railway carriage
  • bridge building

Weathering steel S355J0WP strip

Weathering steel S355J0WP strip

  • Normalized
  • Hot and cold rolled
  • Q and T

BS EN10025-5 S355J0WP steel plate

BS EN10025-5 S355J0WP steel plate

  • Width: 1500 to 3200mm
  • Thickness: 2 to 460mm
  • Length: 6000 to 12000mm
Your requests for EN10025-5 s355j0wp steel sheet supply in Dubai can be met by us as an exporter. Here, you can see all of its properties.
S355j0wp steel sheet mechanical properties
Grade Tensile Strength Rm MPa Min. Yield Strength Reh MPa
Nominal Thickness (mm) Nominal Thickness (mm)
>3 >3 =100 >100 =150 >63 =80 >16 =40 =16 >40 =63 >100 =150 >80 =100
S355J0WP 510/680 470/630 450/600 325 345 355 335 295 315
EN10025 s355j0wp steel plate equivalent
Grade Material # JISG3114 SEW 087 EN 10155 NFA 35-502 BS 4360 UNI ASTM
EN 10025
S355J0WP
1.8945 E 36 WA 3 S355J0WP Fe 510 C1K1 WR 50 A A 588
Weathering steel s355j0wp plate chemical properties
Grade S max Si max Cr P max C max Mn Cu
S355J0WP 0.030 0.40 0.40-0.80 0.035 0.13 0.20-0.60 0.25-0.55
Application of corten steel s355j0wp plate
  • bridge building
  • economizer
  • construction
  • air preheater
  • railway
S355j0wp sheet additional services
  •  Low temperature impacting test
  • As per end user’s demands cutting and welding
  • Ultrasonic test
  • Issued orginal mill test certificate

What are 5 uses of s355j0wp steel plate ?

  • S355J0WP steel plate is ideal for bridges, towers, and other outdoor structures exposed to harsh weather conditions.
  • The unique appearance of weathering steels adds an aesthetic appeal to architectural designs.
  • S355J0WP plates are used in railway cars due to their high strength and weathering resistance.
  • It is used to manufacture shipping containers that withstand prolonged exposure to marine environments.
  • EN10025 S355J0WP steel plates are also used in lighting poles, street furniture, and other urban infrastructure elements due to their longevity and corrosion resistance properties.
How much does s355j0wp steel sheet cost ?

The cost of the S355J0WP steel sheet can depend on the current market conditions, the size and thickness of the sheet and the quantity being purchased. The cost also varies with transportation costs, raw material availability, and additional value added services. Also, different suppliers offer the sheets at different prices depending on their strategies. To get the sheets at the best prices without compromising on quality, contact Ridhi Siddhi Steel Corporation.

What are pros and cons of s355j0wp plate?

The benefits of EN10025-5 S355J0WP steel plate are:

  • It shows excellent weathering resistance
  • It has enhanced corrosion resistance properties
  • It is known for high structural strength
  • It has an attractive, natural and rustic aesthetic appeal

The cons of BSEN10025 S355J0WP steel plate will include:

  • It can be more expensive initially compared to traditional structural steels.
  • During the patina formation process, temporary surface staining in the surrounding areas might occur.
  • Limited availability can also be an issue.
