What is corten steel coil used for?

Corten steel can be used for various outdoor structural and architectural applications due to its unique properties and appearance:

  • Corten steel coil has good aesthetic appeal and can be used in architectural elements like facades, cladding, etc.
  • They can be used in bridge construction for their high strength and corrosion resistance.
  • Due to its weathered appearance, it can be used in outdoor sculptures and artworks.
  • Landscaping features like retaining walls, planters, etc. due to its durability and rustic appearance.
  • Shipping containers and other transportation applications for their weather resistance and strength.

Table of content

Genuine cor-ten coils supplier in India

Corten steel coil

How thick is corten coil in MM?

Corten coils are available in various thicknesses The thickness can vary with specific requirements & applications. The standard thicknesses of the coils range from 1.5 to 3.0 mm or more. Thicker coils may be available for specialized projects. The exact thickness depends on the structural design, strength requirements and the intended use of the steel.

We provide odd-sized corten® slitting coils in Mumbai as a stockist in compliance with requirements.

Corten coil

Corten coil

Cor-ten® coils

Cor-ten® coils

Cor-ten® slitting coils

Cor-ten® slitting coils

What is the maximum temperature for corten® coil?

Corten® coil can withstand elevated temperatures without significant loss of its mechanical properties. The max temp for Cor-ten® coils can reach up to 399 degrees C. Beyond this temperature range, the steel may lose its corrosion resistance and mechanical strength due to the formation of a non protective oxide layer.

In regular length 120″, 96″, and 144″, as well as for bespoke orders, we provide a broad selection of corten corrosion resistance coils at affordable costs.

Corten steel coil specification

Corten steel coil specification



Thickness Width Length
1/4 to 1/2″ 48 to 72 “ 120″
Grades Application Process
A and B heat exchanger, office furniture hot rolled (HR)
As an exporter, we can offer the best quality cut-to-length corten steel hot rolled coils in Dubai. be aware of its additional categories
Different types of corten coil

Corten steel hot rolled coils

Corten steel hot rolled coils

  • 16 GA
  • 18 GA
  • 11 GA and 22 GA

Corten corrosion resistance coils

Corten corrosion resistance coils

  • Thickness: 3/16″ to 1/2″
  • Width: 48″ to 72″
  • ASTM A606-4 and A588

Corten steel cold rolled coils

Corten steel cold rolled coils

  • Chimneys
  • Containers
  • Industrial filters
We provide grade A and B corten steel cold rolled coils with mill TC at the most affordable prices. Please review the equivalent, chemical, and mechanical qualities.
Length and size of cor-ten® coils
Hot Rolled Availability
Length Gauge 1/2″ 3/8″ 5/16″ 1/4″ 3/16″ 7ga. 8ga. 10ga. 11ga. 12ga. 14ga. 16ga.
96”, 120” and 144”
or cut to lengths
Width
48″
60″



Cold Rolled Availability
Length Gauge 18ga. 20ga. 22ga.
120” or cut to lengths Width
48″
Cor-ten® slitting coils equivalent
Material # ASTM SEW 087 EN 10155 UNI NFA 35-502 BS 4360 JIS G3114
1.8967 S355K2G2W
1.8945 E 36 WA 3 S355J0WP WR 50 A Fe 510 C1K1
1.8961 WTSt 37-3 S235J2W Fe 360 DK 1 E 24 W 4
1.8959 A 588 – A 242 Gr. 1 S355J0W Fe 510 C2K1 E 36 WB 3 WR 50 B SMA 50 AW
1.8946 A 242 Type 1 S355J2WP Fe 510 D1K1 E 36 WA 4
1.8965 S355J2G2W SMA 50 CP
1.8963 A 588 Gr. A WTSt 52-3 S355J2G1W Fe 510 D2K1 WR 50 C to
1.8966 A 709 Gr. 50 W S355K2G1W E 36 WB 4
Corten steel hot rolled coils mechanical properties
Metric Imperial
Ultimate Tensile Strength 483 MPa 70,000psi
Density 7.75 g/cc 0.28 lb/in3
Yield Tensile Strength 345 MPa 50,000psi
Corten steel cold rolled coils chemical properties
 Si %
max.
 C %
max.
 Mn % Z%  S %
max.
 P %  N %
max.
 Cr % V%  Cu % Ni% Mo%
According to EN 10027-1 & CR 10260
S235J2W 0.40 0.13 0.20-0.60 0.03 0.04 0.40-0.80 0.25-0.55 0.65
S235J0W 0.40 0.13 0.20-0.60 0.04 0.04 0.01 0.40-0.80 0.25-0.55 0.65
S355J2WP 0.75 0.12 1.00 0.03 0.06-0.15 0.30-1.25 0.25-0.55 0.65
S355J0W 0.75 0.12 1.00 0.04 0.06-0.15 0.01 0.30-1.25 0.25-0.55 0.65
S355J2W 0.50 0.16 0.50-1.50 0.15 0.03 0.03 0.40-0.80 0.25-0.55 0.65 0.30
S355J0W 0.50 0.16 0.50-1.50 0.15 0.04 0.04 0.01 0.40-0.80 0.25-0.55 0.65 0.30
S355K2W 0.50 0.16 0.50-1.50 0.15 0.03 0.03 0.40-0.80 0.25-0.55 0.65 0.30
According to ASTM & ASME Specn.
A 588 Gr. B 0.15-
0.50
0.20 0.75-1.35 0.05 0.04 0.40-0.70 0.01-
0.10
0.20-0.40
A 588 Gr. A 0.3-
0.65
0.19 0.80-1.25 0.05 0.04 0.40-0.65 0.02-
0.10
0.25-0.40
A 588 Gr. C 0.15-
0.40
0.15 0.80-1.35 0.05 0.04 0.30-0.50 0.01-
0.10
0.20-0.50
A 242 Type-1 0.15 1.00 0.05 0.15 0.20 min.
A 588 Gr. K 0.25-
0.50
0.17 0.50-1.20 Cb-0.005
-0.05
0.05 0.04 0.40-0.70 0.30-0.50
A 242 Type-2  0.20 1.50 0.05 0.04 0.20 min.
According to IS STD.
IRSM-41 0.30-
0.50
0.10 0.25-0.45 0.03 0.075-0.14 0.35-0.49 0.05 0.30-0.60 0.28-
0.49
0.05
Application of cor-ten® coils
  • monuments
  • buildings
  • construction projects
  • sculptures

Is corten steel hot rolled coils rust proof?

Corten steel forms a protective rust like patina on its surface when they are exposed to different weather elements. The natural patina acts as a protective layer which enhances corrosion resistance and reduces the rate of further rusting. Corten steel hot rolled coils are not completely rust proof, however, the patina significantly slows down the corrosion process.

What is the price of corten corrosion resistance coils ?

The price of Corten corrosion resistance coils can depend on different factors. It can vary from one supplier to another depending on their internal costing and market conditions. If you are looking for dimensionally accurate coils made of high quality Corten steel at the most competitive price, contact Ridhi Siddhi Steel Corporation.

How do I pick the correct corten steel coil size for my application?

Determine the dimensions and load-bearing capacity needed for your application. Make sure to analyze the budget as well. By doing so, you will be able to pick the correct Corten steel cold rolled coils size for a given application.
