What is ASTM A709 grade HPS 50W weathering steel?

ASTM A709 Grade HPS 50W is a low alloy steel mainly used in bridge fabrication work. The material has high strength and enhanced properties than standard grades of carbon steel. ASTM A709 HPS 50W Weathering steel plate material is a high performance grade and hence used in critical outdoor applications, including complex infrastructure projects. The ASTM A709 grade HPS 50W steel plate also acquire the protective patina on its surface through weathering and hence there is no need for surface treatments.

Table of content

we are a trusted and reasonably priced supplier of ASTM A709 gr HPS 50W plate In India

ASTM A709 grade HPS 50W plate

What should I do if my ASTM A709 HPS 50W plate has any issues ?
  • Contact your supplier and let them know about the problem.
  • You can also book an inspection by a third party to get a deeper understanding of the ASTM A709 grade HPS 50W plate issue and the reason behind it.
  • If the ASTM A709 gr HPS 50W plate is covered by a warranty, review the terms and convey the same to the supplier.

Is it challenging to find an ASTM A709 HPS 50W Weathering steel plate stockist in Mumbai for odd sizes? we specialized in cut to size service

ASTM A709 grade HPS 50W steel plate

ASTM A709 grade HPS 50W steel plate

ASTM A709 HPS 50W plate

ASTM A709 HPS 50W plate

A709 HPS 50W Weathering steel plate

A709 HPS 50W Weathering steel plate

What do experts recommend when buying ASTM A709 gr HPS 50W plate?
  • Always buy high quality ASTM A709 HPS 50W plates from reputed and reliable suppliers like  Ridhi Siddhi Steel Corporation.
  • Before purchasing, ask for MTC and to get a complete understanding of the material quality.
  • Talk to the suppliers about the available customization options.
  • Thoroughly research about the suppliers and shortlist a few. Then reach out to them individually and get a price quotation for the plates as per your requirements.

In Dubai, we are an ASTM A709 HPS 50W plate exporter. Check out our assortment, which comes in thicknesses between 0.50 and 2.00 inches.

ASTM A709 grade HPS 50W plate specification

ASTM A709 grade HPS 50W plate specification



Thickness Width Length
0.50 – 2 inch 72- 120 inch 240-1200 inch
Standard Application Grades
ASTM A709 construction of bridges HPS 50WT, HPS 50WF
We offer ASTM A709 grade HPS 50W structural steel plate in virtually any size, so there is no need to purchase whole lengths with the highest standards
Most frequently used types of A709 gr HPS 50W plate

ASTM A709 gr HPS 50W structural steel plate

ASTM A709 gr HPS 50W structural steel plate

  • Width: 72 – 120 inch
  • Thickness: 0.50 – 2.00 inch
  • Length: 240- 1200 inch

A709 gr HPS 50W plate

A709 gr HPS 50W plate

  • Laser Cutting
  • Flame Cutting
  • Waterjet cutting

ASTM A709 HPS 50W corten weathering steel plate

ASTM A709 HPS 50W corten weathering steel plate

  • Low temperature impacting test
  • High tension test
  • Simulated post-welded heat treatment (PWHT)
As a stockholder, we offer ASTM A709 grade HPS 50W plate stock with Mill TC at the most cheap price, view its properties also
ASTM A709 HPS 50W plate impact properties
GRADE THICKNESS
(in)
MIN LONGITUDINAL INDIVIDUAL VALUE 1)
(ft-lbs)
MIN LONGITUDINAL AVERAGE ENERGY 1)
(ft-lbs)
ZONE 2 TEST TEMP ZONE 1 TEST TEMP ZONE 3 TEST TEMP
HPS 50WT 0.50 – 2.00 20 10 oF 10 oF 10 oF
HPS 50WF 0.50 – 2.00 24 30
Size range of A709 HPS 50W plate
GRADE WIDTH
(in)
THICKNESS
(in)
LENGTH
(in)
HPS 50W 72 – 120 0.50 – 2.00 240 – 1200
ASTM A709 grade HPS 50W steel plate mechanical properties
GRADE THICKNESS
(in)
ELONGATION IN 8″ 2)
(MIN %)
TENSILE STRENGTH
(MIN ksi)
YIELD STRENGTH 1)
(MIN ksi)
ELONGATION IN 2″ 2)
(MIN %)
HPS 50W 0.50 – 2.00 18 70 50 21
Chemical properties of ASTM A709 grade HPS 50W structural steel plate
TYPE MN
(wt %)
C
(MAX wt %)
S
(MAX wt %)
P
(MAX wt %)
MO
(wt %)
ALTOT
(wt %)
SI
(wt %)
V
(wt %)
CU
(wt %)
CR
(wt %)
N
(MAX wt %)
NI
(wt %)
HPS 50W 0.10 – 1.35 0.11 0.006 0.020 0.02 – 0.08 0.010 – 0.040 0.30 – 0.50 0.04 – 0.08 0.25 – 0.40 0.45 – 0.70 0.015 0.25 – 0.40

ASTM A709 HPS 50W vs ASTM A709-50W

ASTM A709 HPS 50W corten weathering steel plate has the added HPS designation. This means they have better high performance properties than ASTM A709-50W material.

What is the production procedure for ASTM A709 grade HPS 50W structural steel plate?

  • The raw materials are melted in a furnace to create molten steel.
  • The molten steel is cast into billets through a continuous casting process.
  • They are heated and passed through rolling mills to reduce their thickness and shape them into plates.
  • The ASTM A709 grade HPS 50W structural steel plates may undergo quenching and tempering to achieve the desired mechanical properties.
  • The plates are given heat treatment to enhance strength and toughness.

What is the minimum order quantity and lead time for ASTM A709 HPS 50W plates?

The minimum order quantity and lead time for A709 gr HPS 50W plates varies with the supplier. If you decide purchasing from Ridhi Siddhi Steel Corporation, there is min order quantity. Talking about the delivery timelines, it will vary with the customization you need and your location. You can contact the suppliers directly to get exact details.
